FMMT720
Document Number: DS33238 Rev. 4 - 2
4 of 7
January 2013
© Diodes Incorporated
A Product Line of
Diodes Incorporated
FMMT720
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Collector-Base Breakdown Voltage
BV
CBO
-40 -95 -
V I
C
= -100µA
Collector-Emitter Breakdown Voltage (Note 10)
BV
CEO
-40 -85 -
V I
C
= -10mA
Emitter-Base Breakdown Voltage
BV
EBO
-7 -8.8 -
V I
E
= -100µA
Collector Cutoff Current
I
CBO
- <1
-100 nA
V
CB
= -35V
Emitter Cutoff Current
I
EBO
- <1
-100 nA
V
EB
= -5.6V
Collector Emitter Cutoff Current
I
CES
- <1
-100 nA
V
CE
= -35V
Static Forward Current Transfer Ratio (Note 10)
h
FE
300 480 -
-
I
C
= -10mA, V
CE
= -2V
300 450 -
I
C
= -0.1A, V
CE
= -2V
180 290 -
I
C
= -1A, V
CE
= -2V
60 130 -
I
C
= -1.5A, V
CE
= -2V
12 22 -
I
C
= -3A, V
CE
= -2V
Collector-Emitter Saturation Voltage (Note 10)
V
CE(sat)
- -26
-40 mV
I
C
=- 0.1A, I
B
= -10mA
- -150
-220 mV
I
C
= -1A, I
B
= -50mA
- -245
-330 mV
I
C
= -1.5A, I
B
= -100mA
Base-Emitter Turn-On Voltage(Note 10)
V
BE(on)
- -0.80
-1.0 V I
C
= -1.5A, V
CE
= -2V
Base-Emitter Saturation Voltage(Note 10)
V
BE(sat)
- -0.89
-1.0 V I
C
= -1.5A, I
B
= -75mA
Output Capacitance
C
obo
- 19 25 pF
V
CB
= -10V, f = 1MHz
Transition Frequency
f
T
150 180 - MHz
V
CE
= -10V, I
C
= -50mA,
f = 100MHz
Turn-On Time
t
on
- 40 - ns
V
CC
= -15V, I
C
= -0.75A
I
B1
= I
B2
= -15mA
Turn-Off Time
t
off
- 435 - ns
Notes: 10.
Measured under pulsed conditions. Pulse width ≤ 300µs. Duty cycle ≤ 2%
