FCX491A
Da
tasheet Number: DS33055 Rev. 5 - 2
4 of 7
www.diodes.com
October 2012
© Diodes Incorporated
FCX491A
A Product Line of
Diodes Incorporated
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
Collector-Base Breakdown Voltage BV
CBO
40 - - V I
C
= 100µA
Collector-Emitter Breakdown Voltage (Note 9) BV
CEO
40 - - V I
C
= 10mA
Emitter-Base Breakdown Voltage BV
EBO
7 - - V I
E
= 100µA
Collector Cutoff Current I
CBO
- - 100 nA V
CB
= 30V
Emitter Cutoff Current I
EBO
- - 100 nA V
EB
= 4V
Emitter Cutoff Current I
CES
- - 100 nA V
CE
= 30V
DC current transfer Static ratio (Note 9) h
FE
300
300
200
35
-
-
-
- -
900
-
-
-
I C = 1mA, V CE = 5V
I
C
= 500mA, V
CE
= 5V
I
C
= 1A, V
CE
= 5V
I
C
= 2A, V
CE
= 5V
Collector-Emitter Saturation Voltage (Note 9) V
CE(sat)
-
-
-
- 0.3
0.5
V
I
C
= 500mA, I
B
= 50mA
I
C
= 1A, I
B
= 100mA
Base-Emitter Saturation Voltage (Note 9) V
BE(sat)
- - 1.1 V I
C
= 1A, I
B
= 100mA
Base-Emitter Turn-on Voltage (Note 9) V
BE(on)
- - 1.0 V I
C
= 1A, V
CE
= 5V
Transitional Frequency f T
150 - - MHz
I
C
= 50mA, V
CE
= 10V
f = 100MHz
Output capacitance C
obo
- - 10 pF V
CB
= 10V, f = 1MHz,
Note: 9. Measured under pulsed conditions. Pulse width ≤ 300µs. Duty cycle ≤ 2%.
