Electrical Characteristics
@T A = 25°C unless otherwise specified
Characteristic Symbol Min Typ Max Unit Test Condition
OFF CHARACTERISTICS
Collector-Base Breakdown Voltage
V
(BR)CBO
-40 ⎯ ⎯ V I
C
= -100
μA, I
E
= 0
Collector-Emitter Breakdown Voltage (Note 4) V (BR)CEO
-40 ⎯ ⎯ V I C = -10mA, I B = 0
Emitter-Base Breakdown Voltage V (BR)EBO
-5 ⎯ ⎯ V I E = -100
μA, I
C = 0
Collector Cutoff Current I CBO
⎯ ⎯
-100
-50
nA
μA V
CB
= -40V, I
E
= 0
V CB = -40V, I E = 0, T A = 150°C
Collector Cutoff Current I CES
⎯ ⎯ -100 nA V CE = -40V, V EB = 0
Emitter Cutoff Current I
EBO
⎯ ⎯ -100 nA V
EB
= -5V, I
C
= 0
ON CHARACTERISTICS (Note 4)
DC Current Gain h FE
300
300
250
160
⎯
⎯
⎯
⎯ ⎯
800
⎯
⎯
⎯
V
CE
= -5V, I
C
= -1mA
V CE = -5V, I C = -100mA
V CE = -5V, I C = -500mA
V
CE
= -5V, I
C
= 1A
Collector-Emitter Saturation Voltage V
CE(SAT)
⎯
⎯
⎯ ⎯
⎯
⎯
-140
-170
-310
mV
I
C
= -100mA, I
B
= -1mA
I
C
= -500mA, I
B
= -50mA
I
C
= -1A, I
B
= -100mA
Collector-Emitter Saturation Resistance R
CE(SAT)
⎯ ⎯ 340 m Ω I
C
= -500mA, I
B
= -50mA
Base-Emitter Saturation Voltage V
BE(SAT)
⎯ ⎯ -1.1 V I
C
= -1A, I
B
= -50mA
Base-Emitter Turn On Voltage V
BE(ON)
⎯ ⎯ -1 V V
CE
= -5V, I
C
= -1A
SMALL SIGNAL CHARACTERISTICS
Output Capacitance
C
obo
⎯ ⎯ 15 pF V
CB
= -10V, f = 1.0MHz
Current Gain-Bandwidth Product f T
150 ⎯ ⎯ MHz V CE = -10V, I C = -50mA, f = 100MHz
SWITCHING CHARACTERISTICS
Turn-On Time
t on
⎯ 55 ⎯ ns
V
CC
= -10V
I
C
= -0.5A, I
B1
= I
B2
= -25mA
Delay Time t d
⎯ 20 ⎯ ns
Rise Time t r
⎯ 35 ⎯ ns
Turn-Off Time t
off
⎯ 255 ⎯ ns
Storage Time t
s
⎯ 225 ⎯ ns
Fall Time t
f
⎯ 30 ⎯ ns
Notes: 4. Measured under pulsed conditions. Pulse width = 300 μs. Duty cycle ≤2%.
0
200
400
25 50 75 100 125 150
P
,
P
O
WE
R
DI
SSI
P
A
T
IO
N
(mW
)
D
T , AMBIENT TEMPERATURE (°C)
Fig. 1 Power Dissipation vs.
Ambient Temperature (Note 3)
A
600
0
R = 208°C/W θJA
300
500
100
0.1 1 10 100
-V , COLLECTOR-EMITTER VOLTAGE (V)
CE
Fig. 2 Typical Collector Current
vs. Collector-Emitter Voltage (Note 3)
0.01
0.1
1
10
-I
,
C
O
LL
E
C
T
O
R
C
U
R
R
E
N
T
(A
)
C
Pw = 100ms
Pw = 10ms
Pw = 1ms
DC
