ELECTRICAL CHARACTERISTICS (at T
amb
= 25°C unless otherwise stated).
PARAMETER SYMBOL
VALUE
UNIT CONDITIONS.
MIN. TYP. MAX.
Collector-Base Breakdown
Voltage V
(BR)CBO
50 85 V I
C
=100
µ
A
Collector-Emitter
Breakdown Voltage V
CES
50 85 V I
C
=100
µ
A*
Collector-Emitter
Breakdown Voltage V
CEO
17.5 24 V I
C
=10mA
Collector-Emitter
Breakdown Voltage V
CEV
50 85 V I
C
=100
µ
A, V
EB
=1V
Emitter-Base Breakdown
Voltage V
(BR)EBO
5 8.7 V I
E
=100
µ
A
Collector Cut-Off Current I
CBO
0.3 10 nA V
CB
=35V
Emitter Cut-Off Current I
EBO
0.3 10 nA V
EB
=4V
Collector Emitter Cut-Off
Current I
CES
0.3 10 nA V
CE
=35V
Collector-Emitter Saturation
Voltage V
CE(sat)
27
55
155
250 45
75
210
350 mV
mV
mV
mV I
C
=0.5A, I
B
=10mA*
I
C
=1A, I
B
=10mA*
I
C
=3A, I
B
=15mA*
I
C
=5A, I
B
=25mA*
Base-Emitter
Saturation Voltage V
BE(sat)
920 1000 mV I
C
=5A, I
B
=25mA*
Base-Emitter Turn-On
Voltage V
BE(on)
880 970 mV I
C
=5A, V
CE
=2V*
Static Forward Current
Transfer Ratio h
FE
280
300
300
180
50 440
450
450
300
80
1200
I
C
=10mA, V
CE
=2V*
I
C
=0.5A, V
CE
=2V*
I
C
=1A, V
CE
=2V*
I
C
=5A, V
CE
=2V*
I
C
=20A, V
CE
=2V*
Transition Frequency f
T
150 MHz I
C
=50mA, V
CE
=10V
f=50MHz
Output Capacitance C
obo
60 80 pF V
CB
=10V, f=1MHz
Switching Times
t
on
120 ns I
C
=4A, I
B
=40mA, V
CC
=10V
t
off
310 ns I
C
=4A, I
B
=40mA, V
CC
=10V
FZT1048A
