FMMT617
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Collector-Base Voltage V
CBO
15 V
Collector-Emitter Voltage V
CEO
15 V
Emitter-Base Voltage V
EBO
7 V
Continuous Collector Current I
C
3 A
Peak Pulse Current (Note 5) I
CM
12 A
Base Current I
B
500 mA
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Power Dissipation (Note 5) P
D
625 mW
Power Dissipation (Note 6) P
D
806 mW
Thermal Resistance, Junction to Ambient (Note 5) R
θJA
200 °C/W
Thermal Resistance, Junction to Ambient (Note 6) R
θJA
155 °C/W
Thermal Resistance, Junction to Leads (Note 7) R
θJL
194 °C/W
Operating and Storage Temperature Range T
J,
T
STG
-55 to +150 °C
ESD Ratings
(Note 8)
Characteristic Symbol Value Unit JEDEC Class
Electrostatic Discharge - Human Body Model ESD HBM 4,000 V 3A
Electrostatic Discharge - Machine Model ESD MM ≥ 400 V C
Notes: 5. For a device surface mounted on 25mm X 25mm FR4 PCB with high coverage of single sided 1 oz copper, in still air conditions; the device is measured
when operating in a steady-state condition.
6. Same as note 5, except the device is measured at t ≤ 5 sec.
7. Thermal resistance from junction to solder-point (at the end of the collector lead).
8. Refer to JEDEC specification JESD22-A114 and JESD22-A115.
