DDZ9689S - DDZ9717S
Document number: DS30409 Rev. 6 - 2
6 of 7
August 2009
© Diodes Incorporated
DDZ9689S - DDZ9717S
-0.08
0.12
-0.04
-0.06
30
42
50
T
C
of
V
,
T
EM
P
E
R
A
T
U
R
E
C
O
E
F
F
IC
IE
N
T
O
F
ZENER
VO
L
T
AG
E (
%
/°
C)
Z
V , ZENER VOLTAGE (V)
Fig. 20 Typical Temperature Coefficient of Zener
Voltage vs. Zener Voltage, DDZ9713S - DDZ9716S
Z
38
34
46
-0.02
0
0.02
0.04
0.06
0.08
0.10
Ordering Information
(Note 6)
Part Number
Case
Packaging
(Type Number)-7*
SOD-323
3000/Tape & Reel
*Example: The part number for the 6.2 Volt device would be DDZ9691S-7.
Notes:
6. For packaging details, go to our website at
Marking Information
Package Outline Dimensions
SOD-323
Dim Min Max
A
0.25 0.35
B
1.20 1.40
C
2.30 2.70
H
1.60 1.80
J
0.00 0.10
K
1.0 1.1
L
0.20 0.40
M
0.10 0.15
α
0° 8°
All Dimensions in mm
xx = Product Type Marking Code
(See Electrical Characteristics Table)
XX
K
L
M
J
C
H
B
A
