DFLZ5V1 - DFLZ39
POWERDI is a registered trademark of Diodes Incorporated.
1.0W SURFACE MOUNT POWER ZENER DIODE
POWERDI  123
Features
 1W Power Dissipation on FR-4 PCB
 Lead-Free Finish; RoHS Compliant (Notes 1 & 2)
 Halogen and Antimony Free. “Green” Device (Note 3)
 Qualified to AEC-Q101 Standards for High Reliability
 Patented Interlocking Clip Design for High Surge Capacity,
US Patent #7,095,113
Mechanical Data
 Case: POWERDI123
 Case Material: Molded Plastic, “Green” Molding Compound. UL
Flammability Classification Rating 94V-0
 Moisture Sensitivity: Level 1 per J-STD-020
 Terminal Connections: Cathode Band
 Terminals: Finish - Matte Tin annealed over Copper leadframe.
Solderable per MIL-STD-202, Method 208
 Weight: 0.01 grams (approximate)
Ordering Information
(Note 4)
Part Number Case Packaging
(Type Number)-7* POWERDI  123 3000/Tape & Reel
* Add “-7” to the appropriate type number in Electrical Characteristics Table. Example: 6.2V Zener = DFLZ6V2-7
Notes: 1. EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant. All applicable RoHS exemptions applied.
2. See http://www.diodes.com for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Marking Information
Date Code Key
Year 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018
Code U V W X Y Z A B C D E F
Month Jan Feb Mar Apr May Jun Jul Aug Sep Oct Nov Dec
Code 1 2 3 4 5 6 7 8 9 O N D
Top View
Fxx = Product Type Marking Code
(See Electrical Characteristics Table)
YM = Date Code Marking
Y = Year (ex: A = 2013)
M = Month (ex: 9 = September)
Fxx
YM
Green
