GBU10005 - GBU1010
Document number: DS30052 Rev. 6 - 2
1 of 4
www.diodes.com
November 2012
© Diodes Incorporated
GBU10005 - GBU1010
10A GLASS PASSIVATED BRIDGE RECTIFIER
Features
•
Glass Passivated Die Construction
•
High Case Dielectric Strength of 1500V
RMS
•
Low Reverse Leakage Current
•
Surge Overload Rating to 220A Peak
• Ideal for Printed Circuit Board Applications
• UL Listed Under Recognized Component
Index, File Number E94661
• Lead-Free Finish; RoHS Compliant (Notes 1 & 2)
Mechanical Data
• Case:
GBU
• Case Material: Molded Plastic. UL Flammability Classification
Rating 94V-0
• Moisture Sensitivity: Level 1 per J-STD-020
• Terminals: Matte Tin Finish. Solderable per MIL-STD 202, Method
208
• Polarity: Marked on Body
• Mounting: Through Hole for #6 Screw
•
Mounting Torque: 5.0 Inch-pounds Maximum
•
Marking: Date Code and Type Number
• Weight: 4 grams (approximate)
Ordering Information
(Note 3)
Part Number Case Packaging
GBU10005-GBU1010 GBU 20/Tube
Notes: 1. EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant. All applicable RoHS exemptions applied.
2. See http://www.diodes.com for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and Lead-free.
3. For packaging details, go to our website at http://www.diodes.com.
Maximum Ratings and Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Characteristic Symbol
GBU
10005
GBU
1001 GBU
1002 GBU
1004 GBU
1006 GBU
1008 GBU
1010
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage V
RRM
V
RWM
V
R
50 100 200 400 600 800 1000 V
RMS Reverse Voltage V
R(RMS)
35 70 140 280 420 560 700 V
Average Forward Rectified Current (Note 4) @ T
C
= +100
°C I
(AV)
10 A
Non-Repetitive Peak Forward Surge Current
8.3ms Single Half Sine-Wave Superimposed on Rated Load
I
FSM
220 A
Forward Voltage (per element) @ I
F
= 5.0A V
FM
1.0 V
Peak Reverse Current at
Rated DC Blocking Voltage @ T
C
= +25 °C
@ T
C
= +125 °C
I
R
5.0
500
μA
I
2
t Rating for Fusing (Note 5) I
2
t 200 A
2
s
Typical Total Capacitance per Element (Note 6) C
T
60 pF
Typical Thermal Resistance Junction to Case (Note 4) R θJC 2.2 °C/W
Operating and Storage Temperature Range T J, T STG
-55 to +150 °C
Notes: 4. Unit mounted on 100mm x 100mm x 1.6mm copper plate heatsink.
5. Non-repetitive, for t > 1.0ms and < 8.3ms.
6. Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
Pb
