Diodes GBJ6005 - GBJ610 User Manual
0a glass passivated bridge rectifier features, Mechanical data, Maximum ratings and electrical characteristics

e
3
DS21216 Rev. 7 - 2
1 of 3
GBJ6005-GBJ610
www.diodes.com
ã
Diodes Incorporated
Characteristic
Symbol
GBJ
6005
GBJ
601
GBJ
602
GBJ
604
GBJ
606
GBJ
608
GBJ
610
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
50
100
200
400
600
800
1000
V
RMS Reverse Voltage
V
R(RMS)
35
70
140
280
420
560
700
V
Average Forward Rectified Output Current
@ T
C
= 110°C
I
O
6.0
A
Non-Repetitive Peak Forward Surge Current, 8.3 ms single
half-sine-wave superimposed on rated load
I
FSM
170
A
Forward Voltage per element
@ I
F
= 3.0A
V
FM
1.0
V
Peak Reverse Current
@ T
C
= 25°C
at Rated DC Blocking Voltage
@ T
C
= 125°C
I
R
5.0
500
µA
I
2
t Rating for Fusing (t < 8.3ms) (Note 1)
I
2
t
120
A
2
s
Typical Total Capacitance per Element (Note 2)
C
T
55
pF
Typical Thermal Resistance Junction to Case (Note 3)
R
qJC
1.8
°C/W
Operating and Storage Temperature Range
T
j
, T
STG
-65 to +150
°C
GBJ6005 - GBJ610
6.0A GLASS PASSIVATED BRIDGE RECTIFIER
Features
·
Case: GBJ
·
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
·
Moisture Sensitivity: Level 1 per J-STD-020C
·
Lead Free Plating (Tin Finish).
·
Terminals: Plated Leads, Solderable per MIL-STD-202,
Method 208
·
Polarity: Molded on Body
·
Mounting: Through Hole for #6 Screw
·
Mounting Torque: 5.0 in-lbs Maximum
·
Marking: Type Number
·
Weight: 6.6 grams (approximate)
Mechanical Data
Notes:
1. Non-repetitive, for t > 1ms and < 8.3 ms.
2. Measured at 1.0 MHz and applied reverse voltage of 4.0V DC.
3. Thermal resistance from junction to case per element. Unit mounted on 75 x 75 x 1.6mm aluminum plate heat sink.
4. RoHS revision 13.2.2003. Glass and High Temperature Solder Exemptions Applied, see
·
Glass Passivated Die Construction
·
High Case Dielectric Strength of 1500V
RMS
·
Low Reverse Leakage Current
·
Surge Overload Rating to 170A Peak
·
Ideal for Printed Circuit Board Applications
·
UL Listed Under Recognized Component
Index, File Number E94661
·
Lead Free Finish/RoHS Compliant (Note 4)
Single phase, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Maximum Ratings and Electrical Characteristics
@ T
A
= 25°C unless otherwise specified
GBJ
Dim
Min
Max
A
29.70
30.30
B
19.70
20.30
C
17.00
18.00
D
3.80
4.20
E
7.30
7.70
G
9.80
10.20
H
2.00
2.40
I
0.90
1.10
J
2.30
2.70
K
3.0 X 45°
L
4.40
4.80
M
3.40
3.80
N
3.10
3.40
P
2.50
2.90
R
0.60
0.80
S
10.80
11.20
All Dimensions in mm
_
B
C
D
E
E
G
H
K
J
I
L
M
N
P
R
S
A
