ES1A - ES1G
Document number: DS14001 Rev. 16 - 2
2 of 4
www.diodes.com
November 2011
© Diodes Incorporated
ES1A - ES1G
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol ES1A ES1B ES1C ES1D ES1G Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage (Note 5) V
RRM
V
RWM
V R
50 100 150 200 400 V
RMS Reverse Voltage V
R(RMS)
35 70 105 140 280 V
Average Rectified Output Current @ T
T
= 110 °C I
O
1.0 A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
30 A
Thermal Characteristics
Characteristic Symbol Value Unit
Typical Thermal Resistance, Junction to Terminal (Note 4) R θJT 25 °C/W
Operating and Storage Temperature Range T J, T STG
-55 to +150 °C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol ES1A ES1B ES1C ES1D ES1G Unit
Maximum Forward Voltage Drop
I F = 0.6A
I
F
= 1.0A
V FM
0.90
0.92 ⎯
1.25
V
Peak Reverse Current
at Rated DC Blocking Voltage (Note 5) T
A
= 25
°C
T
A
= 125 °C
I
RM
5.0
200
μA
Maximum Reverse Recovery Time (Note 6) t rr
25 ns
Typical Total Capacitance (Note 7) C
T
20 pF
Notes: 4. Unit mounted on PC board with 5.0 mm 2 (0.013 mm thick) copper pad as heat sink.
5. Short duration pulse test used to minimize self-heating effect.
6. Measured with I
F
= 0.5A, I
R
= 1.0A, I
rr
= 0.25A. See figure 5.
7. Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
0.5
25 50 75 100 125 150 175
I,
A
V
E
R
A
G
E
R
E
C
T
IF
IE
D
C
U
R
R
EN
T
(A
)
O
T , TERMINAL TEMPERATURE ( C)
Fig. 1 Forward Current Derating Curve
T
°
1.0
1.5
0
Note 5
0.01
0.1
1.0
10
0 0.4 0.8 1.2 1.6
I,
I
N
S
T
A
N
T
A
N
E
O
U
S
F
O
R
WA
R
D
C
U
R
R
E
N
T
(A
)
F
V , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
F
