MBR2535CT - MBR2560CT

30A SCHOTTKY BARRIER RECTIFIER

Features

L

M

A

N

P

D

E

K

C

B

G

1 2 3

J

H H

Pin 1

Pin 3

Pin 2

Case

Maximum Ratings and Electrical Characteristics

@ T

A

= 25

°C unless otherwise specified

·

Schottky Barrier Chip

·

Guard Ring Die Construction for
Transient Protection

·

Low Power Loss, High Efficiency

·

High Surge Capability

·

High Current Capability and Low Forward Voltage Drop

·

For Use in Low Voltage, High Frequency Inverters, Free
Wheeling, and Polarity Protection Applications

·

Lead Free Finish, RoHS Compliant (Note 4)

Mechanical Data

Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.

Characteristic

Symbol

MBR2535CT

MBR2545CT

MBR2550CT

MBR2560CT

Unit

Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage

V

RRM

V

RWM

V

R

35

45

50

60

V

RMS Reverse Voltage

V

R(RMS)

25

32

35

42

V

Average Rectified Output Current

@ T

C

= 130

°C

I

O

30

A

Non-Repetitive Peak Forward Surge Current 8.3ms
single half sine-wave superimposed on rated load
(JEDEC Method)

I

FSM

150

A

Peak Repetitive Reverse Surge Current (Note 3)

I

RRM

1.0

0.5

A

Forward Voltage Drop @ I

F

= 15.0A, T

C

= 25

°C

@ I

F

= 15.0A, T

C

= 125

°C

@ I

F

= 30.0A, T

C

= 25

°C

@ I

F

= 30.0A, T

C

= 125

°C

V

FM

¾

¾

0.82
0.73

0.75
0.65

¾

¾

V

Peak Reverse Current

@ T

C

= 25

°C

at Rated DC Blocking Voltage

@ T

C

= 125

°C

I

RM

0.2

40

1.0

50

mA

Typical Total Capacitance (Note 2)

C

T

750

500

pF

Typical Thermal Resistance Junction to Case (Note 1)

R

qJC

1.5

°C/W

Operating and Storage Temperature Range

T

j,

T

STG

-65 to +150

°C

Notes:

1. Thermal resistance junction to case mounted on heatsink.

2. Measured at 1.0MHz and Applied Reverse Voltage of 4.0V DC.
3. 2.0

ms pulse width, f = 1.0KHz.

4. RoHS revision 13.2.2003. Glass and High Temperature Solder Exemptions Applied, see

EU Directive Annex Notes 5 and 7.

·

Case: TO-220AB

·

Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0

·

Moisture Sensitivity: Level 1 per J-STD-020C

·

Terminals: Finish – Bright Tin. Solderable per
MIL-STD-202, Method 208

·

Polarity: As Marked on Body

·

Marking: Type Number

·

Weight: 2.24 grams (approx.)

TO-220AB

Dim

Min

Max

A

14.48

15.75

B

10.00

10.40

C

2.54

3.43

D

5.90

6.40

E

2.80

3.93

G

12.70

14.27

H

2.40

2.70

J

0.69

0.93

K

3.54

3.78

L

4.07

4.82

M

1.15

1.39

N

0.30

0.50

P

2.04

2.79

All Dimensions in mm
