Diodes DFLS160 User Manual
Dfls160, Features, Mechanical data

DFLS160
Document number: DS30548 Rev. 7 - 2
1 of 4
December 2011
© Diodes Incorporated
DFLS160
POWERDI is a registered trademark of Diodes Incorporated.
1.0A SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER
POWERDI
®
123
Features
•
Guard Ring Die Construction for Transient Protection
•
Low Power Loss, High Efficiency
•
Patented Interlocking Clip Design for High Surge Current
Capacity
•
Qualified to AEC-Q101 Standards for High Reliability
•
Lead Free Finish, RoHS Compliant (Note 1)
•
Green Molding Compound (No Br, Sb)
Mechanical Data
• Case:
POWERDI
®
123
•
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
•
Terminal Connections: Cathode Band
•
Terminals: Finish – Matte Tin annealed over Copper
leadframe. Solderable per MIL-STD-202 Method 208
•
Weight: 0.01 grams (approximate)
Ordering Information
(Note 2)
Part Number
Case
Packaging
DFLS160-7 POWERDI
®
123
3000/Tape & Reel
Notes:
1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied, see EU Directive 2002/95/EC Annex Notes
2. For packaging details, go to our website at
Marking Information
Date Code Key
Year
2004
2005
2006
2007
2008
2009
2010
2011
2012
2013
2014
2015
2016
2017
Code
R
S
T
U
V
W
X
Y
Z
A
B
C
D
E
Month
Jan
Feb
Mar
Apr
May
Jun
Jul
Aug
Sep
Oct
Nov
Dec
Code
1 2 3 4 5 6 7 8 9 O N D
Top View
F17 = Product Type Marking Code
YM = Date Code Marking
Y = Year (ex: R = 2004)
M = Month (ex: 9 = September)
F17
YM
POWERDI
®
123
