POWERDI is a registered trademark of Diodes Incorporated.

DFLS2100

Document number: DS31475 Rev. 3 - 2

2 of 4

www.diodes.com

October 2012

© Diodes Incorporated

DFLS2100





Maximum Ratings

(@T

A

= +25°C, unless otherwise specified.)

Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.

Characteristic Symbol

Value

Unit

Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage

V

RRM

V

RWM

V

R

100 V

RMS Reverse Voltage

V

R(RMS)

71 V

Average Forward Current

I

F(AV)

2.0 A

Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load

I

FSM

40 A



Thermal Characteristics

Characteristic Symbol

Typ

Max

Unit

Thermal Resistance Junction to Soldering (Note 5)

R

θJS

— 7 °C/W

Thermal Resistance Junction to Ambient (Note 6) (T

A

= +25°C)

R

θJA

125 — °C/W

Operating and Storage Temperature Range

T

J

, T

STG

-55 to +175

°C



Electrical Characteristics

(@T

A

= +25°C, unless otherwise specified.)

Characteristic Symbol

Min

Typ

Max

Unit

Test

Condition

Reverse Breakdown Voltage (Note 7)

V

(BR)R

100

V

I

R

= 1

μA

Forward Voltage

V

F

0.77
0.86

V

I

F

= 1.0A

I

F

= 2.0A

Leakage Current (Note 7)

I

R

1

μA

V

R

= 100V, T

A

= +25

°C

Total Capacitance

C

T

36

pF

V

R

= 5VDC, f = 1MHz

Notes:

5. Theoretical R

θJS

calculated from the top center of the die straight down to the PCB/cathode tab solder junction.

6. Part mounted on FR-4 board with 2 oz., minimum recommended copper pad layout, which can be found on our website at http://www.diodes.com.

7. Short duration pulse test used to minimize self-heating effect.




0

0.2

0.4

0.6

2

1.8

1.6

1.4

1.2

1

0.8

0

0.5

3

1

1.5

2.5

2

3.5

P

,

P

O

WE

R

DISS

IP

A

T

IO

N (

W

)

D

I

, AVERAGE FORWARD CURRENT (A)

Fig. 1 Forward Power Dissipation

F(AV)

0.00001

0.0001

0.01

0.001

10

1

0.1

0.2

0.1

0

0.4 0.5

0.3

0.6 0.7 0.8 0.9 1.0

I,

I

N

S

T

AN

T

AN

E

O

U

S

F

O

R

WA

R

D

C

U

R

R

EN

T

(A

)

F

V , INSTANTANEOUS FORWARD VOLTAGE (V)

Fig. 2 Typical Forward Characteristics

F

T = 125 C

A

°

T = 150 C

A

°

T = 175 C

A

°

T = 25 C

A

°

T = -55 C

A

°

T = 75 C

A

°
