B0520LW
Document number: DS30051 Rev. 15 - 2
3 of 4
www.diodes.com
October 2012
© Diodes Incorporated
B0520LW
C
,
T
O
T
A
L
CAP
A
CIT
A
NCE (
p
F
)
T
V , DC REVERSE VOLTAGE (V)
Fig. 3 Total Capacitance vs. Reverse Voltage
R
1,000
1.0
10
100
0 5 10 15 20
f = 1MHz
0
0.25
0.50
0 50 100 150
I,
A
V
E
R
A
G
E
R
E
C
T
IF
IE
D
C
U
R
R
E
N
T
(A
)
O
T , LEAD TEMPERATURE ( C)
Fig. 4 Forward Current Derating Curve
L
°
0.75
1.0
25 75 125
Note 6
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
Suggested Pad Layout
Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.
SOD123
Dim Min Max
A 0.55 Typ
B 1.40 1.70
C 3.55 3.85
H 2.55 2.85
J 0.00 0.10
K 1.00 1.35
L 0.25 0.40
M 0.10 0.15
α 0 8°
All Dimensions in mm
Dimensions Value (in mm)
G 2.250
X 0.900
X1 4.050
Y 0.950
K
L
M
C
H
B A
Y
X
X1
G
