B1100LB
Document number: DS30077 Rev. 10 - 2
3 of 4
www.diodes.com
September 2010
© Diodes Incorporated
B1100LB
0
1
2
4
3
25 50 75 100 125 175
I A
V
E
R
A
G
E
F
O
R
WA
R
D
C
U
R
R
E
N
T
(A
)
F(
A
V
),
T , TERMINAL TEMPERATURE ( C)
Fig. 3 Forward Current Derating Curve
T
°
150
10
20
30
40
50
0
1 10 100
I,
P
E
AK
F
O
R
WA
R
D S
U
R
G
E
C
U
R
R
EN
T
(A
)
FS
M
NUMBER OF CYCLES AT 60Hz
Fig. 4 Max Non-Repetitive Peak Forward Surge Current
Package Outline Dimensions
Suggested Pad Layout
SMB
Dim Min Max
A 3.30 3.94
B 4.06 4.57
C 1.96 2.21
D 0.15 0.31
E 5.00 5.59
G 0.05 0.20
H 0.76 1.52
J 2.00 2.50
All Dimensions in mm
Dimensions Value (in mm)
Z 6.8
G 1.8
X 2.3
Y 2.5
C 4.3
A
B
C
D
G H
E
J
