B130L
1.0A SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER
Features
•
Low Forward Voltage Drop
•
Guard Ring Die Construction for Transient Protection
•
Ideally Suited for Automated Assembly
•
Low Power Loss, High Efficiency
•
Lead Free Finish, RoHS Compliant (Note 1)
•
Green Molding Compound (No Halogen and Antimony)
(Note 4)
Mechanical Data
•
Case: SMA
•
Case Material: Molded Plastic. UL Flammability Classification
Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020D
•
Terminals: Lead Free Plating (Matte Tin Finish). Solderable
per MIL-STD-202, Method 208
•
Polarity: Cathode Band or Cathode Notch
•
Marking Information: See Page 3
•
Ordering Information: See Page 3
•
Weight: 0.064 grams (approximate)
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic
Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage @ I
R
= 1mA
Blocking Voltage
V
RRM
V
RWM
V
R
30
V
RMS Reverse Voltage
V
R(RMS)
21
V
Average Rectified Output Current
@ T
T
= 105
°C
I
O
1.0
A
Peak Repetitive Forward Current (Note 2)
I
FRM
2.0
A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
25
A
Thermal Characteristics
Characteristic
Symbol
Value
Unit
Typical Thermal Resistance Junction to Terminal
R
θJT
27
°C/W
Operating Temperature Range
T
J
-55 to +125
°C
Storage Temperature Range
T
STG
-55 to +150
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
Forward Voltage Drop
V
F
-
-
-
-
-
-
-
-
0.41
0.35
0.47
0.43
V
I
F
= 1.0A, T
J
= 25
°C
I
F
= 1.0A,
T
J
= 100
°C
I
F
= 2.0A,
T
J
= 25
°C
I
F
= 2.0A,
T
J
= 100
°C
Leakage Current (Note 3)
I
R
-
-
-
-
-
-
-
-
0.4
12
1.0
25
mA
V
R
= 15V,
T
A
= 25
°C
V
R
= 15V,
T
A
= 100
°C
V
R
= 30V,
T
A
= 25
°C
V
R
= 30V,
T
A
= 100
°C
Total Capacitance
C
T
-
-
110
pF
V
R
= 4V, f = 1MHz
Notes:
1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at
R
, Square Wave, 25KHz, T
C
= 40°C.
3. Short duration pulse test used to minimize self-heating effect.
4. Product manufactured with Data Code 0924 (week 24, 2009) and newer are built with Green Molding Compound.
Top View
Bottom View
Green
