B220/A - B260/A
Document number: DS13004 Rev. 21 - 2
2 of 5
www.diodes.com
April 2013
© Diodes Incorporated
B220/A - B260/A
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol B220/A B230/A B240/A B250/A B260/A Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage V
RRM
V
RWM
V
R
20 30 40 50 60 V
RMS Reverse Voltage V
R(RMS)
14 21 28 35 42 V
Average Rectified Output Current @ T
L
= +100°C I
O
2.0 A
Non-Repetitive Peak Forward Surge Current, 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
50 A
Thermal Characteristics
Characteristic Symbol Value Unit
Typical Thermal Resistance, Junction to Lead
SMA
SMB
R
θJL
25
20
°C/W
Operating and Storage Temperature Range T
J,
T
STG
-65 to +150 °C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
Forward Voltage Drop
B220/A, B230/A, B240/A
B250/A, B260/A
V
F
— —
0.50
0.70
V I
F
= 2.0A, T
A
= +25°C
Leakage Current (Note 5) I
R
-—
—
—
—
0.5
20
mA
@ Rated V
R
, T
A
= +25°C
@ Rated V
R
, T
A
= +100°C
Total Capacitance C
T
— — 200 pF V
R
= 4V, f = 1MHz
Note: 5. Short duration pulse test used to minimize self-heating effect.
0.01
0.1
1.0
10
0 0.2 0.4 0.6 0.8 1.0
I
, INS
TAN
TANE
O
U
S
F
O
R
WA
R
D
C
U
R
R
EN
T
(A
)
F
V , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 1 Typical Forward Characteristics
F
0 20 40 60 80 100 120 140
I,
IN
S
TA
N
TA
N
E
O
U
S
R
EVE
R
SE
C
U
R
R
E
N
T
(mA
)
R
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
Fig. 2 Typical Reverse Characteristics
100
10
1.0
0.1
0.01
0.001
