74LVCE1G125
SINGLE BUFFER GATE WITH 3-STATE OUTPUT
74LVCE1G125
Document number: DS32216 Rev. 2 - 2
6 of 14
December 2010
© Diodes Incorporated
NEW PROD
UC
T
Switching Characteristics
Over recommended free-air temperature range, CL = 15pF (see Figure 1)
Parameter
From
(Input)
TO
(OUTPUT)
Vcc = 1.5 V
± 0.1V
Vcc = 1.8 V
± 0.15V
Vcc = 2.5 V
± 0.2V
Vcc = 3.3 V
± 0.3V
Vcc = 5 V
± 0.5V
Unit
Min
Max
Min
Max
Min
Max
Min
Max
Min
Max
t
pd
A
Y
1.9 6.9 1.3 4.8 0.5 3.6 0.4 3 0.4 3 ns
Over recommended free-air temperature range, CL = 30 or 50pF as noted (see Figure 2)
Parameter
From
(Input)
TO
(OUTPUT)
Vcc = 1.5 V
± 0.1V
Vcc = 1.8 V
± 0.15V
Vcc = 2.5 V
± 0.2V
Vcc = 3.3 V
± 0.3V
Vcc = 5 V
± 0.5V
Unit
Min
Max
Min
Max
Min
Max
Min
Max
Min
Max
t
pd
A
Y
2.8 9 1.9 6.3 0.9 4.4 0.8 3.6 0.9 3.6 ns
t
en
OE
Y
3.3 10.1
2.3 7 1.2 5.2 0.8 4.3 0.9 4.5
t
dis
OE Y
1.3
9.2
0.9
6.4
0.8 4 0.8 4.1 0.9 3.7
Operating Characteristics
T
A
= 25 ºC
Parameter
Test
Conditions
Vcc = 1.5 V Vcc = 1.8 V Vcc = 2.5 V Vcc = 3.3 V Vcc = 5 V
Unit
TYP
TYP
TYP
TYP
TYP
C
pd
Power
dissipation
capacitance
Outputs
enabled
f = 10 MHz
20 20 20 21 22
pF
Outputs
disabled
2 2 2 2 4
