74LVC1G14
Document number: DS35123 Rev. 4 - 2
6 of 16
March 2014
© Diodes Incorporated
74LVC1G14
Package Characteristics
(All typical values are at V
CC
= 3.3V, T
A
= +25°C)
Symbol
Parameter
Test Conditions
V
CC
Min
Typ.
Max
Unit
θ
JA
Thermal Resistance
Junction-to-Ambient
SOT25
(Note 9)
— 204
—
°C/W
SOT353 —
371
—
SOT553 —
231
—
X2-DFN0808-4 —
400
—
X1-DFN1010-6 —
435
—
X2-DFN1010-6 —
445
—
X2-DFN1409-6 —
470
—
X2-DFN1410-6 —
460
—
θ
JC
Thermal Resistance
Junction-to-Case
SOT25
(Note 9)
— 52
—
°C/W
SOT353 —
143
—
SOT553 —
105
—
X2-DFN0808-4 —
225
—
X1-DFN1010-6 —
250
—
X2-DFN1010-6 —
250
—
X2-DFN1409-6 —
275
—
X2-DFN1410-6 —
265
—
Note: 9. Test condition for each of the 8 package types: Device mounted on FR-4 substrate PC board, 2oz copper, with minimum recommended pad layout.
Switching Characteristics
T
A
= -40°C to +85°C, C
L
= 15pF as noted (see Figure 1)
Parameter
From
Input
To
Output
V
CC
= 1.8V
± 0.15V
V
CC
= 2.5V
± 0.2V
V
CC
= 3.3V
± 0.3V
V
CC
= 5V
± 0.5V
Unit
Min Max Min Max Min Max Min Max
t
pd
A
Y
1.0 9.9 0.7 5.5 0.7 4.6 0.7 4.4 ns
T
A
= -40°C to +85°C, C
L
= 30 or 50pF as noted (see Figure 2)
Parameter
From
Input
To
Output
V
CC
= 1.8V
± 0.15V
V
CC
= 2.5V
± 0.2V
V
CC
= 3.3V
± 0.3V
V
CC
= 5V
± 0.5V
Unit
Min Max Min Max Min Max Min Max
t
pd
A
Y
1.0 11 0.7 6.5 0.7 5.5 0.7 5
ns
T
A
= -40°C to +125°C, C
L
= 15pF as noted (see Figure 1)
Parameter
From
Input
To
Output
V
CC
= 1.8V
± 0.15V
V
CC
= 2.5V
± 0.2V
V
CC
= 3.3V
± 0.3V
V
CC
= 5V
± 0.5V
Unit
Min Max Min Max Min Max Min Max
t
pd
A
Y
1.0 12.5 0.7 7.5 0.7 6.5 0.7 5.5 ns
T
A
= -40°C to +125°C, C
L
= 30 or 50pF as noted (see Figure 2)
Parameter
From
Input
To
Output
V
CC
= 1.8V
± 0.15V
V
CC
= 2.5V
± 0.2V
V
CC
= 3.3V
± 0.3V
V
CC
= 5V
± 0.5V
Unit
Min Max Min Max Min Max Min Max
t
pd
A
Y
1.0 14.0 0.7 8.5 0.7 7.0 0.7 6.5 ns
