74LVC1G02
Parameter Measurement Information
V
CC
Inputs
V
M
C
L
R
L
V
I
t
r
/t
f
1.8V ± 0.15V V
CC
≤2ns V
CC
/2 30pF 1kΩ
2.5V ± 0.2V V
CC
≤2ns V
CC
/2 30pF 500Ω
2.7V V
CC
≤2.5ns 1.5V 50pF 500Ω
3.3V ± 0.3V 3.0V ≤2.5ns 1.5V 50pF 500Ω
5.0V ± 0.5V V
CC
≤2.5ns V
CC
/2 50pF 500Ω
Voltage Waveform Pulse Duration
Voltage Waveform Propagation Delay Times
Inverting and Non Inverting Outputs
Figure 1. Load Circuit and Voltage Waveforms
Notes: A. Includes test lead and test apparatus capacitance.
B. All pulses are supplied at pulse repetition rate ≤ 10 MHz.
C. Inputs are measured separately one transition per measurement.
D. t
PLH
and t
PHL
are the same as t
PD
.
