74AUP1G86
Electrical Characteristics
(cont.) (@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter
Test
Conditions
Vcc
T
A
= -40 to 125
o
C
Unit
Min Max
V
IH
High-Level Input
Voltage
0.8V to 1.65V
0.80 X V
CC
V
1.65V to 1.95V
0.70 X V
CC
2.3V to 2.7 V
1.6
3.0V to 3.6V
2.0
V
IL
Low-Level Input
Voltage
0.8V to 1.65V
0.25 X V
CC
V
1.65V to 1.95V
0.30 X V
CC
2.3V to 2.7V
0.7
3.0V to 3.6V
0.9
V
OH
High-Level Output
Voltage
I
OH
= -20
μA
0.8V to 3.6V
V
CC
– 0.11
V
I
OH
= -1.1mA
1.1V
0.6 X V
CC
I
OH
= -1.7mA
1.4V 0.93
I
OH
= -1.9mA
1.65V 1.17
I
OH
= -2.3mA
2.3V
1.77
I
OH
= -3.1mA
1.67
I
OH
= -2.7mA
3V
2.40
I
OH
= -4 mA
2.30
V
OL
Low-Level Output
Voltage
I
OL
= 20
μA
0.8V to 3.6V
0.11
V
I
OL
= 1.1mA
1.1V
0.33 X V
CC
I
OL
= 1.7mA
1.4V 0.41
I
OL
= 1.9mA
1.65V
0.39
I
OL
= 2.3mA
2.3V
0.36
I
OL
= 3.1mA
0.50
I
OL
= 2.7mA
3V
0.36
I
OL
= 4mA
0.50
I
I
Input Current
A or B Input
V
I
=GND to 3.6V
0 to 3.6V
±0.75
μA
I
OFF
Power Down
Leakage Current
V
I
or V
O
= 0 to 3.6V
0 ±3.5
μA
ΔI
OFF
Delta Power Down
Leakage Current
V
I
or V
O
= 0 to 3.6V
0 to 0.2V
±2.5
μA
I
CC
Supply Current
V
I
= GND or V
CC
, I
O
= 0
0.8V to 3.6V
3.0
μA
ΔI
CC
Additional Supply
Current
Input at V
CC
-0.6V Other
inputs at V
CC
or GND
3.3V
75
μA
