74AUP1G07
Document number: DS35149 Rev. 2 - 2
4 of 14
www.diodes.com
July 2013
© Diodes Incorporated
74AUP1G07
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter Test Conditions V
CC
T A = +25°C T A = -40°C to +85°C
Unit
Min Max Min Max
V
IH
High-Level Input
Voltage
0.8V to 1.65V 0.80 X V
CC
0.80 X V
CC
V
1.65V to 1.95V 0.65 X V
CC
0.65 X V
CC
2.3V to 2.7V 1.6 1.6
3.0V to 3.6V 2.0 2.0
V
IL
Low-Level Input
Voltage
0.8V to 1.65V 0.30 X V CC 0.30 X V CC
V
1.65V to 1.95V 0.35 X V CC 0.35 X V CC
2.3V to 2.7V 0.7 0.7
3.0V to 3.6V 0.9 0.9
V
OL
Low-Level
Output Voltage
I
OL
= 20 μA 0.8V to 3.6V 0.1 0.1
V
I
OL
= 1.1mA 1.1V 0.3 X V
CC
0.3 X V
CC
I
OL
= 1.7mA 1.4V 0.31 0.37
I
OL
= 1.9mA 1.65V 0.31 0.35
I
OL
= 2.3mA
2.3V
0.31 0.33
I
OL
= 3.1mA 0.44 0.45
I
OL
= 2.7mA
3V
0.31 0.33
I
OL
= 4mA 0.44 0.45
I I
Input Current
A or B Input
V
I
= GND to 3.6V
0V to 3.6V ± 0.1 ± 0.5 μA
I
OFF
Power Down
Leakage Current
V
I
or V
O
= 0V to 3.6V 0 ± 0.2 ± 0.5 μA
I
OZ
Z State
Leakage Current V
O
= 3.6V
V
i
= 3.6V
3.6V ± 0.2 ± 0.5 μA
ΔI
OFF
Delta Power
Down Leakage
Current
V
I
or V
O
= 0V to 3.6V 0V to 0.2V 0.2 0.6 μA
I
CC
Supply Current V
I
= GND or V
CC
, I
O
=0 0.8V to 3.6V 0.5 0.9 μA
ΔI
CC
Additional
Supply Current Input at V
CC
-0.6V
3.3V 40 50 μA
