74AHCT1G86
SINGLE 2 INPUT EXCLUSIVE-OR GATE
74AHCT1G86
Document number: DS35185 Rev. 1 - 2
3 of 8
www.diodes.com
May 2011
© Diodes Incorporated
NEW PROD
UC
T
Absolute Maximum Ratings (Note 2)
Symbol Description Rating Unit
ESD HBM Human Body Model ESD Protection 2 KV
ESD CDM Charged Device Model ESD Protection 1 KV
ESD MM Machine Model ESD Protection 200 V
V
CC
Supply Voltage Range -0.5 to 6.5 V
V
I
Input Voltage Range -0.5 to 6.5 V
V
O
Voltage applied to output in high or low state -0.5 to V
CC
+0.5 V
I
IK
Input Clamp Current V
I
<0 -20 mA
I
OK
Output Clamp Current (V
O
< 0 or V
O
> V
CC
) ±20 mA
I
O
Continuous output current (V
O
= 0 to V
CC
) ±25 mA
I
CC
Continuous current through V
CC
50 mA
I
GND
Continuous current through GND -50 mA
T
J
Operating Junction Temperature -40 to 150 °C
T
STG
Storage Temperature -65 to 150 °C
Notes: 2. Stresses beyond the absolute maximum may result in immediate failure or reduced reliability. These are stress values and device operation should be
within recommend values.
Recommended Operating Conditions (Note 3)
Symbol Parameter Min Max Unit
V
CC
Operating Voltage 4.5 5.5 V
V
IH
High-level Input Voltage 2.0 V
V
IL
Low-level input voltage 0.8 V
V
I
Input Voltage 0 5.5 V
V
O
Output Voltage 0 V
CC
V
I
OH
High-level output current -8 mA
I
OL
Low-level output current 8 mA
Δt/ΔV
Input transition rise or fall
rate
20 ns/V
T
A
Operating free-air
temperature
-40 125 ºC
Notes: 3. Unused inputs should be held at V CC or Ground.
