74AHC1G08
SINGLE 2 INPUT POSITIVE AND GATE
74AHC1G08
Document number: DS35172 Rev. 1 - 2
4 of 8
www.diodes.com
March 2011
© Diodes Incorporated
NEW PROD
UC
T
Electrical Characteristics
Symbol Parameter Test Conditions V
CC
25ºC -40ºC to 85ºC -40ºC to 125ºC
Unit
Min Typ. Max Min Max Min Max
V
OH
High Level
Output Voltage
I
OH
= -50 μA
2V 1.9 2 1.9 1.9
V
3V 2.9 3 2.9 2.9
4.5V 4.4 4.5 4.4 4.4
I
OH
= -4mA 3V 2.58 2.48 2.40
I
OH
= -8mA
4.5V 3.94 3.8 3.70
V
OL
High-level Input
Voltage
I
OL
= 50 μA
2V 0.1 0.1 0.1
V
3V 0.1 0.1 0.1
4.5V 0.1 0.1 0.1
I
OL
= 4mA 3V 0.36 0.44 0.55
I
OL
= 8mA 4.5V 0.36 0.44 0.55
I
I
Input Current V
I
= 5.5 V or GND 0 to 5.5V ± 0.1 ± 1 ± 2 μA
I
CC
Supply Current
V
I
= 5.5V or GND
I
O
=0
5.5V 1 10 40 μA
C
I
Input
Capacitance V
I
= V
CC
– or GND
5.5V 2.0 10 10 10 pF
θ
JA
Thermal
Resistance
Junction-to-
Ambient
SOT25
(Note 4)
195
o C/W
SOT353 430
θ
JC
Thermal
Resistance
Junction-to-
Case
SOT25
(Note 4)
58
o
C/W
SOT353 155
Note: 4. Test conditions for SOT25, and SOT353: Device mounted on FR-4 substrate PC board, 2oz copper, with minimum recommended pad layout
Switching Characteristics
V
CC
= 3.3V ± 0.3 (see Figure 1)
Parameter
From
(Input)
TO
(OUTPUT)
25ºC -40ºC to 85ºC -40ºC to 125ºC
Unit
Min Typ. Max Min Max Min Max
t
pd
A or B Y
C
L
=15pF 0.6 4.6 8.8 0.6 10.5 0.6 12.0 ns
C
L
=50pF 0.6 6.5 12.3 0.6 14.0 0.6 16.0 ns
V
CC
= 5V ± 0.5V (see Figure 1)
Parameter
From
(Input)
TO
(OUTPUT)
25ºC -40ºC to 85ºC -40ºC to 125ºC
Unit
Min Typ. Max Min Max Min Max
t
pd
A or B Y
C
L
=15pF 0.6 3.2 5.9 0.6 7.0 0.6 8.0 ns
C
L
=50pF 0.6 4.6 7.9 0.6 9.0 0.6 10.5 ns
