74LVC86A
Document number: DS35264 Rev. 3 - 2
5 of 10
June 2012
© Diodes Incorporated
74LVC86A
Switching Characteristics
Symbol
Parameter
Test
Conditions
V
CC
T
A
= +25°C
-40°C to +85°C -40°C to +125°C
Unit
Min
Typ
Max Min Max Min Max
t
PD
Propagation
Delay A
N
or B
N
to Y
N
Figure 1
1.65V
to1.95V
1.0
4.1
9.4 1.0 9.9 1.0 11.4
ns
2.3V
to
2.7V 1.0
2.9
7.1 1.0 7.6 1.0 9.7
2.7V
1.0
2.8
5.4 1.0 5.6 1.0 7.1
3.0V
to
3.6V 1.0
2.5
4.4 1.0 4.6 1.0 5.8
t
SK(0)
Output Skew
Time
3.0V to 3.6V
1.0
1.5
ns
Operating Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Parameter
Test
Conditions
V
CC
= 1.8V
V
CC
= 2.5V
V
CC
= 3.3V
Unit
Typ Typ Typ
C
pd
Power dissipation
capacitance per gate
f = 10 MHz
6.4
7.4
8.4
pF
C
I
Input Capacitance
V
i
= V
CC
– or
GND
4 4 4 pF
Package Characteristics
Symbol
Parameter
Test Conditions
V
CC
Min Typ Max Unit
θ
JA
Thermal Resistance
Junction-to-Ambient
SO-14
(Note 6)
TBD
o
C/W
TSSOP-14
159
θ
JC
Thermal Resistance
Junction-to-Case
SO-14
(Note 6)
TBD
o
C/W
TSSOP-14
25
Note:
6. Test condition for SO-14 and TSSOP-14: Device mounted on FR-4 substrate PC board, 2oz copper, with minimum recommended pad layout.
