74LVC06A
Document number: DS35259 Rev. 3 - 2
5 of 10
July 2012
© Diodes Incorporated
74LVC07A
Switching Characteristics
Symbol
Parameter
Test
Conditions
V
CC
T
A
= +25°C
-40°C to +85°C -40°C to +125°C
Unit
Min Typ Max Min Max Min Max
t
PLZ
/t
PZL
Propagation
Delay A
N
to Y
N
Figure 1
1.65V to1.95V
0.3
2.9
5.7
0.3
5.8
0.3
7.6
ns
2.3V to 2.7V
0.3
2.6
4.1
0.3
4.7
0.3
5.5
2.7V 0.3
2.5
4.0
0.3
4.5
0.3
5.0
3V to 3.6V
0.3
2.3
3.5
0.3
3.7
0.3
5.0
4.5V to 5.5V
0.3
1.7
3.2
0.3
3.4
0.3
4.5
Operating Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Parameter
Test
Conditions
V
CC
= 1.8V
V
CC
= 2.5V
V
CC
= 3.3V
V
CC
= 5V
Unit
Typ Typ Typ Typ
C
pd
Power dissipation
capacitance per gate
f = 10 MHz
7.0
7.5
8.0
8.6
pF
C
I
Input Capacitance
V
I
= V
CC
– or
GND
4 4 4 4
pF
Package Characteristics
Symbol
Parameter
Test Conditions
V
CC
Min
Typ
Max
Unit
θ
JA
Thermal Resistance
Junction-to-Ambient
SO-14
(Note 6)
TBD
°C/W
TSSOP-14
159
θ
JC
Thermal Resistance
Junction-to-Case
SO-14
(Note 6)
TBD
°C/W
TSSOP-14
25
Note:
6. Test condition for SO-14 and TSSOP-14: Device mounted on FR-4 substrate PC board, 2oz copper, with minimum recommended pad layout.
