74LVC04A
Document number: DS35258 Rev. 3 - 2
6 of 10
www.diodes.com
July 2012
© Diodes Incorporated
74LVC04A
Parameter Measuement Information
V
CC
Inputs
V
M
C
L
R
L
V
I
t
r
/t
f
1.8V ±0.15V V
CC
≤2ns V
CC
/2 30pF 1K Ω
2.5V ±0.2V V
CC
≤2ns V
CC
/2 30pF 500 Ω
3.3V ±0.3V 3V ≤2.5ns 1.5V 50pF 500Ω
5V ±0.5V V
CC
≤2.5ns V
CC
/2 50pF 500 Ω
Voltage Waveform
Pulse Duration
Voltage Waveform
Propagation Delay Times
Inverting and Non Inverting Outputs
Notes: A. Includes test lead and test apparatus capacitance.
B. All pulses are supplied at pulse repetition rate ≤ 10 MHz.
C. Inputs are measured separately one transition per measurement.
D. t
PLH
and t
PHL
are the same as t
PD.
Figure 1. Load Circuit and Voltage Waveforms
