74LV08A
Switching Characteristics
Symbol Parameter
Test
Conditions
V
CC
T
A
= +25°C -40°C to +85°C -40°C to +125°C
Unit
Min Typ Max Min Max Min Max
t
PD
Propagation
Delay A
N
to Y
N
Figure 1
C
L
= 15pF
2.5V ± 0.2V – 7.9 13.8 1 16 1 17
ns 3.3V ± 0.3V – 5.6 8.8 1 10.5 1 11.5
5.0V ± 0.5V – 4.1 5.9 1 7 1 8
Figure 1
C
L
= 50 pF
2.5V ± 0.2V – 10.5 17.3 1 20 1 21
ns 3.3V ± 0.3V – 7.5 12.5 1 14 1 15
5.0V ± 0.5V – 5.5 7.9 1 9 1 10
Operating Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Parameter
Test
Conditions
V
CC
Typ Unit
C
pd
Power Dissipation
Capacitance per Gate
F= 10 MHz
C
L
=50pF
3.3V 8
pF
5.0V 10
Noise Characteristics
V
CC
= 3V, C
L
= 50pF T
A
= +25°C
Symbol Parameter Min Typ Max Unit
V
OL(p)
Quiet output, maximum dynamic V
OL
— 0.2 0.8 V
V
OL(V)
Quiet output, minimum dynamic V
OL
— -0.1 -0.8 V
V
OH(V)
Quiet output, minimum dynamic V
OH
— 3.1 — V
V
IH(D)
High Level dynamic input voltage 2.31 — — V
V
IL(D)
Low Level dynamic input voltage — — 0.99 V
Package Characterisitics
Symbol Parameter Test Conditions V
CC
Min Typ Max Unit
C
i
Input Capacitance V
i
= V
CC
– or GND 2.0 to 5.5V — 3.3 10 pF
