Recommended Operating Conditions
(Note 5) (@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter Conditions Min Max Unit
V
CC
Supply Voltage — 2.0 5.5 V
V
I
Input Voltage — 0 5.5 V
V
O
Output Voltage — 0 V
CC
V
I
OH
High-Level Output Current
2.0V — -50 mA
2.3V to 2.7V — -2 μA
3.0V to 3.6V — -6 mA
4.5V to 5.5V — -12 mA
I
OL
Low-Level Output Current
2.0V — 50 μA
2.3V to 2.7V — 2 mA
3.0V to 3.6V — 6 mA
4.5V to 5.5V — 12 mA
Δt/ΔV
Input Transition Rise or Fall
Rate
2.3V to 2.7V — 200
ns/V 3.0V to 3.6V — 100
4.5V to 5.5V — 20
T
A
Operating Free-Air
Temperature
— -40 +125 °C
Note: 5. Unused inputs should be held at V
CC
or Ground.
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter Test Conditions V
CC
T
A
= -40°C to +85°C T
A
= -40°C to +125°C
Unit
Min Max Min Max
V
IH
High-Level Input
Voltage
— 2.0V 1.5 — 1.5 —
V — 2.3V to 2.7V V
CC
X 0.7 — V
CC
X 0.7 —
— 3.0V to 3.6V V
CC
X 0.7 — V
CC
X 0.7 —
— 4.5V to 5.5V V
CC
X 0.7 — V
CC
X 0.7 — —
V
IL
Low-Level Input
Voltage
— 2.0V — 0.5 — 0.5
V — 2.3V to 2.7V — V
CC
X 0.3 — V
CC
X 0.3
— 3.0V to 3.6V — V
CC
X 0.3 — V
CC
X 0.3
— 4.5V to 5.5V — V
CC
X 0.3 — V
CC
X 0.3 —
V
OH
High-Level
Output Voltage
I
OH
= -50μA 2.0V to 5.5V V
CC
-0.1 — V
CC
-0.1 —
V
I
OH
= -2mA 2.3V 2.0 — 2.0 —
I
OH
= -6mA 3.0V 2.48 — 2.48 —
I
OH
= -12mA 4.5V 3.8 — 3.8 —
V
OL
Low-Level
Output Voltage
I
OL
= 50μA 2.0V to 5.5V — 0.1 — 0.1
V
I
OL
= 2mA 2.3V — 0.4 — 0.4
I
OL
= 6mA 3.0V — 0.44 — 0.44
I
OL
= 12mA 4.5V — 0.55 — 0.55
I
OFF
Power Down
Leakage Current V
I
or V
O
= 0 to 5.5V 0V — 5 — 5 μA
I
I
Input Current V
I
= GND or 5.5V 0 to 5.5V — ±1 — ±1 μA
I
CC
Supply Current
V
I
= GND or V
CC
I
O
= 0
5.5V — 20 — 20 μA
