74HC04
Document number: DS35320 Rev. 3- 2
4 of 8
January 2013
© Diodes Incorporated
74HC04
NEW PROD
UC
T
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Symbol
Parameter
Test Conditions
V
CC
T
A
= -40°C to +85°C
T
A
= -40°C to +125°C
Unit
Min Max Min Max
V
IH
High-level Input
Voltage
2.0V
1.5 1.5
V
4.5V
3.15 3.15
6.0V
4.2 4.2
V
IL
Low-level input
voltage
2.0V 0.5 0.5
V
4.5V 1.35 1.35
6.0V 1.8 1.8
V
OH
High-level Output
Voltage
I
OH
= -20μA
2.0V
1.9 1.9
V
I
OH
= -20μA
4.5V
4.4 4.4
I
OH
= -20μA
6.0V
5.9 5.9
I
OH
= -4.0mA
4.5V
3.84 3.7
I
OH
= -5.2mA
6.0V
5.34 5.2
V
OL
Low level Output
Voltage
I
OL
= 20μA
2.0V 0.1 0.1
V
I
OL
= 20μA
4.5V 0.1 0.1
I
OL
= 20μA
6.0V 0.1 0.1
I
OL
= 4mA
4.5V 0.33 0.44
I
OL
= 5.2mA
6.0V 0.33 0.44
I
I
Input Current
V
I
=GND to 5.5V
6.0V ±
1 ±
1
μA
I
CC
Supply Current
V
I
= GND or V
CC
, I
O
=0
6.0V 20 40
μA
Switching Characteristics
Symbol
Parameter
Test
Conditions
V
CC
T
A
= +25°C
-40°C to +85°C
-40°C to +125°C
Unit
Min Typ Max
Max
Max
t
PD
Propagation
Delay A
N
to Y
N
Figure 1
C
L
=50 pF
2.0V —
25
90 115
135
ns
4.5V
—
9
18
23
27
6.0V —
7
15 20
23
t
t
Transition time
Figure 1
C
L
=50 pF
2.0V —
19
75 95
110
ns
4.5V
—
7
15
19
22
6.0V —
6
13 16
19
Operating Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Parameter Test
Conditions
V
CC
= 6V
Unit
Typ
C
pd
Power Dissipation
Capacitance per Gate
f = 1 MHz
22
pF
C
I
Input Capacitance
V
I
= V
CC
– or GND
4 pF
