74HC00
Document number: DS35319 Rev. 3 - 2
5 of 8
www.diodes.com
January 2013
© Diodes Incorporated
74HC00
NEW PROD
UC
T
Parameter Measurement Information
Vcc
Inputs
V
M
C
L
V
I
t
r
/t
f
2.0V to 6.0V V
CC
6ns V
CC
/2 15pF,50pF
Voltage Waveform
Pulse Duration
Voltage Waveform
Propagation Delay Times
Inverting and Non Inverting Outputs
Notes: A . Includes test lead and test apparatus capacitance.
B. All pulses are supplied at pulse repetition rate ≤ 1 MHz
C. Inputs are measured separately one transition per measurement
D. t
PLH
and t
PHL
are the same as t
PD
Figure 1 Load Circuit and Voltage Waveforms
