74AHC138
Document number: DS35482 Rev. 2 - 2
6 of 10
www.diodes.com
June 2013
© Diodes Incorporated
Preliminary
74AHC138
Operating Characteristics (@T
A
= +25°C, unless otherwise specified.)
Parameter Test Conditions
V
CC
= 5 V
Unit
TYP
C
pd
Power dissipation capacitance f = 1 MHz all outputs switching-no load 18 pF
Parameter Measurement Information
Vcc
Inputs
V
M
C
L V
I
t
r
/t
f
2.0V -6.0V V
CC
6ns V
CC
/2 50pF
5.0V V
CC
6ns V
CC
/2 15pF used for 5V typical test
Voltage Waveform
Pulse Duration
Voltage Waveform
Propagation Delay Times
Inverting and Non Inverting Outputs
Notes: A . Includes test lead and test apparatus capacitance.
B. All pulses are supplied at pulse repetition rate ≤ 10 MHz
C. Inputs are measured separately one transition per measurement
D. t
PLH
and t
PHL
are the same as t
PD
Figure 1. Load Circuit and Voltage Waveforms
