74AHC00
Document number: DS35338 Rev. 3 - 2
3 of 8
January 2013
© Diodes Incorporated
NEW PROD
UC
T
74AHC00
Recommended Operating Conditions
(Note 5) (@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter
Conditions
Min
Max
Unit
V
CC
Supply Voltage
2.0
5.5
V
V
I
Input Voltage
0
5.5
V
V
O
Output Voltage
0
V
CC
V
Δt/ΔV
Input Transition Rise or Fall Rate
V
CC
= 3.0V to 3.6V
100
ns/V
V
CC
= 4.5V to 5.5V
20
T
A
Operating Free-Air Temperature
-40
+125
°C
Note:
5. Unused inputs should be held at V
CC
or Ground.
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter Test
Conditions
V
CC
T
A
= -40°C to +85°C
T
A
= -40°C to +125°C
Unit
Min Max Min Max
V
IH
High-Level Input
Voltage
2.0V
1.5
1.5
V
3.0V
2.1
2.1
5.5V
3.85
3.85
V
IL
Low-Level Input
Voltage
2.0V
0.5
0.5
V
3.0V
0.9
0.9
5.5V
1.65
1.65
V
OH
High-Level Output
Voltage
I
OH
= -50μA
2.0V 1.9 1.9
V
I
OH
= -50μA
3.0V 2.9 2.9
I
OH
= -50μA
4.5V 4.4 4.4
I
OH
= -4mA
3.0V 2.48 2.40
I
OH
= -8mA
4.5V 3.80 3.70
V
OL
Low-Level Output
Voltage
I
OL
= 50μA
2.0V
0.1
0.1
V
I
OL
= 50μA
3.0V
0.1
0.1
I
OL
= 50μA
4.5V
0.1
0.1
I
OL
= 4mA
3.0V
0.44
0.55
I
OL
= 8mA
4.5V
0.44
0.55
I
I
Input Current
V
I
= GND to 5.5V
3.6V ±1 ±2
μA
I
CC
Supply Current
V
I
= GND or V
CC
, I
O
=0
3.6V 20 40
μA
Operating Characteristics
Parameter
Test
Conditions
V
CC
= 2.0V
V
CC
= 3.3V
V
CC
= 5
Unit
Typ Typ Typ
C
pd
Power Dissipation
Capacitance per Gate
f = 1MHz
9.7
11.0
14.8
pF
C
i
Input Capacitance
V
i
= V
CC
– or GND
4.0 4.0 4.0 pF
