74LVC2G14
Recommended Operating Conditions
(Note 5) (@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter Min Max Unit
V
CC
Operating Voltage
Operating 1.65 5.5 V
Data retention only 1.5 — V
V
I
Input Voltage 0 5.5 V
V
O
Output Voltage 0 V
CC
V
I
OH
High-Level Output Current
V
CC
= 1.65V — -4
mA
V
CC
= 2.3V — -8
V
CC
= 3V
— -16
— -24
V
CC
= 4.5V — -32
I
OL
Low-Level Output Current
V
CC
= 1.65V — 4
mA
V
CC
= 2.3V — 8
V
CC
= 3V
— 16
— 24
V
CC
= 4.5V — 32
∆t/∆V Input transition rise or fall rate
V
CC
= 1.8V ± 0.15V, 2.5V ± 0.2V — 20
ns/V V
CC
= 3.3V ± 0.3V — 10
V
CC
= 5V ± 0.5V — 5
T
A
Operating free-air temperature — -40 +125 ºC
Note: 5. Unused inputs should be held at V
CC
or Ground.
