74LVC2G06
Document number: DS35161 Rev. 5 - 2
2 of 11
October 2013
© Diodes Incorporated
74LVC2G06
Pin Descriptions
Pin Name
Pin NO.
Function
1A 1
Data
Input
GND 2
Ground
2A 3
Data
Input
2Y
4
Data Output Open Drain
V
CC
5
Supply Voltage
1Y
6
Data Output Open Drain
Logic Diagram
1
6
1Y
1A
3
4
2Y
2A
Function Table
Inputs
Output
A
Y
H L
L Z
Absolute Maximum Ratings
(Note 4) (@T
A
= +25°C, unless otherwise specified.)
Symbol
Description
Rating
Unit
ESD HBM
Human Body Model ESD Protection
2
kV
ESD CDM
Charged Device Model ESD Protection
1
kV
ESD MM
Machine Model ESD Protection
200
V
V
CC
Supply Voltage Range
-0.5 to +6.5
V
V
I
Input Voltage Range
-0.5 to +6.5
V
V
O
Voltage applied to output in high impedance or I
OFF
state
-0.5 to +6.5
V
V
O
Voltage applied to output in high or low state
-0.3 to V
CC
+0.5
V
I
IK
Input Clamp Current V
I
< 0
-50 mA
I
OK
Output Clamp Current V
O
< 0
-50 mA
I
O
Continuous Output Current
-50
mA
Continuous Current Through V
DD
or GND
±100 mA
T
J
Operating Junction Temperature
-40 to +150
°C
T
STG
Storage Temperature
-65 to +150
°C
Note: 4. Stresses beyond the absolute maximum may result in immediate failure or reduced reliability. These are stress values and device operation should be
within recommend values.
