74AUP2G04
NEW PROD
UC
T
Pin Descriptions
Pin Name
Pin NO
Function
1A 1
Data
Input
GND 2
Ground
2A 3
Data
Input
2Y 4
Data
Output
V
CC
5
Supply Voltage
1Y 6
Data
Output
Function Table
Inputs Output
nA nY
H L
L H
Logic Diagram
1
6
1Y
1A
3
4
2Y
2A
Absolute Maximum Ratings
(Note 4)
(@T
A
= +25°C, unless otherwise specified.)
Symbol
Description
Rating
Unit
ESD HBM
Human Body Model ESD Protection
2
kV
ESD CDM
Charged Device Model ESD Protection
1
kV
ESD MM
Machine Model ESD Protection
200
V
V
CC
Supply Voltage Range
-0.5 to +4.6
V
V
I
Input Voltage Range
-0.5 to +4.6
V
V
o
Voltage applied to output in high or low state
-0.5 to V
CC
+0.5
V
I
IK
Input Clamp Current V
I
<0
50
mA
I
OK
Output Clamp Current (V
O
< 0 )
-50 mA
I
O
Continuous Output Current (V
O
= 0 to V
CC
)
±20 mA
I
CC
Continuous Current through V
CC
50
mA
I
GND
Continuous Current through GND
-50
mA
T
J
Operating Junction Temperature
-40 to +150
°C
T
STG
Storage Temperature
-65 to +150
°C
Note:
4. Stresses beyond the absolute maximum may result in immediate failure or reduced reliability. These are stress values and device operation should be
within recommend values.
