ADJUSTABLE PRECISION SHUNT REGULATORS AZ431-B
Parameter
Symbol
Value
Unit
Cathode Voltage
V
KA
20
V
Cathode Current Range (Continuous)
I
KA
-100 to 150
mA
Reference Input Current Range
I
REF
10
mA
Power Dissipation
P
D
Z, R Package: 770
mW
N, K Package: 370
Junction Temperature
T
J
150
o
C
Storage Temperature Range
T
STG
-65 to 150
o
C
ESD (Human Body Model)
ESD
2000
V
Parameter
Symbol
Min
Max
Unit
Cathode Voltage
V
KA
V
REF
18
V
Cathode Current
I
KA
1.0 100
mA
Operating Ambient
Temperature Range
T
A
-40
125
o
C
Recommended Operating Conditions
Note 2: Stresses greater than those listed under "Absolute Maximum Ratings" may cause permanent damage to the
device. These are stress ratings only, and functional operation of the device at these or any other conditions beyond
those indicated under "Recommended Operating Conditions" is not implied. Exposure to "Absolute Maximum
Ratings" for extended periods may affect device reliability.
Absolute Maximum Ratings (Note 2)
