1A LOW DROPOUT LINEAR REGULATOR AP2218
Data Sheet
3-PIN MICROPROCESSOR RESET CIRCUITS AZ809/AZ810
5
Dec. 2012 Rev. 1. 4
BCD Semiconductor Manufacturing Limited
(T
A
=-40
o
C to 105
o
C, Typical values at T
A
=25
o
C, V
CC
=5V for L devices, V
CC
=3.3V for T/S devices and V
CC
=3V
for R devices, unless otherwise specified.)
Parameter
Symbol
Conditions
Min
Typ
Max
Unit
Input Voltage (V
CC
) Range
V
CC
T
A
=0
o
C to 70
o
C
1.1
5.5
V
T
A
=-40
o
C to 105
o
C
1.2
5.5
Supply Current
I
CC
T
A
=-40
o
C to 85
o
C,
V
CC
<5.5V,
L
11
20
μA
T
A
=-40
o
C to 85
o
C,
V
CC
<3.6V,
R/S/T
8
16
T
A
=85
o
C to 105
o
C,
V
CC
<5.5V,
L
25
T
A
=85
o
C to 105
o
C,
V
CC
<3.6V,
R/S/T
20
Detect Voltage
V
TH
L Devices
L: 4.63V
T
A
=25
o
C
4.56
4.63
4.70
V
T
A
=-40
o
C to 85
o
C
4.50
4.75
T
A
=85
o
C to 105
o
C
4.40
4.86
T Devices
T: 3.08V
T
A
=25
o
C
3.04
3.08
3.11
T
A
=-40
o
C to 85
o
C
3.00
3.15
T
A
=85
o
C to 105
o
C
2.92
3.23
S Devices
S: 2.93V
T
A
=25
o
C
2.89
2.93
2.96
T
A
=-40
o
C to 85
o
C
2.85
3.00
T
A
=85
o
C to 105
o
C
2.78
3.08
R Devices
R: 2.63V
T
A
=25
o
C
2.59
2.63
2.66
T
A
=-40
o
C to 85
o
C
2.55
2.70
T
A
=85
o
C to 105
o
C
2.50
2.76
Detect Voltage Temperature
Coefficient
±
0.003
%/
o
C
V
CC
to Reset Delay
V
CC
=V
TH
to V
TH
-100mV
20
μs
Electrical Characteristics
