3-TERMINAL 1A ADJUSTABLE VOLTAGE REGULATOR AZ317
Data Sheet
4
Jan. 2013 Rev. 1. 6 BCD Semiconductor Manufacturing Limited
Parameter Symbol Min Max Unit
Input Voltage V
IN
V
OUT
+2 15 V
Operating Junction Temperature Range T
J
0 125 o
C
Recommended Operating Conditions
Note1: Stresses greater than those listed under "Absolute Maximum Ratings" may cause permanent damage to the
device. These are stress ratings only, and functional operation of the device at these or any other conditions beyond
those indicated under "Recommended Operating Conditions" is not implied. Exposure to "Absolute Maximum
Ratings" for extended periods may affect device reliability.
Parameter Symbol Min Max Unit
Input Voltage V
IN
20 V
Maximum Junction Temperature T
J
150 o
C
Storage Temperature T
S
-65 150 o
C
Lead Temperature (Soldering, 10sec) T
LEAD
300 o C
ESD (Human Body Model) ESD 4000 V
Absolute Maximum Ratings (Note 1)
