AS78XXA

Document number: DS36562 Rev.

3 - 2

6 of 23

www.diodes.com

September 2013

© Diodes Incorporated

AS78XXA

A Product Line of

Diodes Incorporated

Electrical Characteristics

(Cont.)

AS7806A

(@ V

IN

= 11V, I

OUT

= 1A, T

J

= -40 to +125°C, unless otherwise specified.)

Symbol Parameter

Conditions

Min

Typ

Max

Unit

V

OUT

Output Voltage

T

J

= +25°C

5.88 6 6.12

V

I

OUT

= 5mA to 1A, V

IN

= 8.6V to

21V, P

D

15W

5.76 – 6.24

V

RLINE

Line Regulation

V

IN

= 8.6V to 21V,

I

OUT

= 500mA, T

J

= +25°C

25 60 mV

V

RLOAD

Load Regulation

V

IN

= 11V, I

OUT

= 5mA to 1A, T

J

=

+25°C

– 20 60 mV

I

Q

Quiescent Current

V

IN

= 11V, I

OUT

= 0

– 3.2 6 mA

I

Q

Quiescent Current Change

V

IN

= 8.6V to 21V, I

OUT

= 500mA,

T

J

= +25°C

– 0.3 0.8

mA

I

OUT

= 5mA to 1A, T

J

= +25°C

– 0.08 0.5

PSRR Ripple

Rejection

V

IN

= 9.5V to 19.5V, f = 120Hz,

I

OUT

= 500mA

– 65 – dB

V

DROP

Dropout Voltage

V

OUT

= 1%, I

OUT

= 1A, T

J

=

+25°C

– 2 – V

N

O

Output Noise Voltage

f = 10Hz to 100kHz, T

A

= 25°C

– 10 –

µV/V

O

R

O

Output Resistance

f = 1kHz

– 10 – mΩ

I

SC

Short Circuit Current

V

IN

= 35V, T

A

= +25°C

– 0.2 – A

I

PK

Peak Output Current

V

IN

= 11V, T

J

= +25°C

– 2.2 – A

V

OUT

/△T

Output Voltage Temperature
Coefficient

– –

0.5

mV/°C

(△V

OUT

/V

OUT

)/

T

– 80 –

ppm/°C

θ

JC

Thermal Resistance

TO-220-3

– 9 –

°C/W

TO-252-2 (3)/
TO-252-2 (4)/
TO-252-2 (5)

– 16 –

TO-220F-3

– 9 –
