LOW POWER DUAL OPERATIONAL AMPLIFIERS AS358/358A
5
BCD Semiconductor Manufacturing Limited Jan. 2013 Rev. 2. 2
Data Sheet
Limits in standard typeface are for T
A
=25
o
C, bold typeface applies over -40
o
C to 85
o
C (Note 2), V
CC
=5V, GND=0V, unless
otherwise specified.
Electrical Characteristics
Parameter Symbol Test Conditions Min Typ Max Unit
Input Offset Voltage V
IO
V
O
=1.4V, R
S
=0 Ω,
V
CC
=5V to 30V
AS358
2 5
mV
7
AS358A
2 3
5
Average Temperature Coeffi-
cient of Input Offset Voltage
ΔV
IO
/ ΔT T
A
=-40 to 85 o C 7 μV/ o C
Input Bias Current I
BIAS
I
IN
+ or I
IN
-, V
CM
=0V
20 200
nA
200
Input Offset Current I
IO
I
IN
+ - I
IN
-, V
CM
=0V
5 30
nA
100
Input Common Mode Voltage
Range (Note 3)
V
IR
V
CC
=30V 0 V
CC
-1.5 V
Supply Current I
CC
T
A
=-40 to 85
o
C, R
L
= ∞, V
CC
=30V
0.7 2
mA
T
A
=-40 to 85 o C, R
L
= ∞, V
CC
=5V
0.5 1.2
Large Signal Voltage Gain G
V
V
CC
=15V, V
O
=1V to 11V, R
L
≥ 2kΩ
85 100
dB
80
Common Mode Rejection
Ratio
CMRR DC, V
CM
=0V to (V
CC
-1.5)V
60 70
dB
60
Power Supply Rejection
Ratio
PSRR V
CC
=5V to 30V
70 100
dB
60
Channel Separation CS f=1kHz to 20kHz -120 dB
Output Current
Source I
SOURCE
V
IN
+=1V, V
IN
-=0V, V
CC
=15V, V
O
=2V
20 40
mA
20
Sink I
SINK
V
IN
+=0V, V
IN
-=1V, V
CC
=15V, V
O
=2V
10 15
mA
5
V
IN
+=0V,V
IN
-=1V,V
CC
=15V, V
O
=0.2V 12 50 μA
Output Short Circuit Current
to Ground
I
SC
V
CC
=15V 40 60 mA
Output Voltage Swing
V
OH
V
CC
=30V, R
L
=2k Ω
26
V
26
V
CC
=30V, R
L
=10k Ω
27 28
27
V
OL
V
CC
=5V, R
L
= 10kΩ
5 20
mV
30
Thermal Resistance
(Junction to Case)
θ
JC
DIP-8 53
o C/W
SOIC-8 78
Note 2: Limits over the full temperature are guaranteed by design, but not tested in production.
