AP358

LOW POWER DUAL OPERATIONAL AMPLIFIERS

AP358

Document number: DS31007 Rev. 6 - 2

15 of 16

www.diodes.com

© Diodes Incorporated

Package Outline Dimensions

(All Dimensions in mm)

(1) Package type: SOP- 8L

1.27typ

0.3/0.5

7°~9°

4.85/4.95

3.85/3.95

5.90/6.10

0.

15/0.25

7°~9°

0.62/0.82

0.10/0.20

Gauge Plane

0.254

Seating Plane

0.35max. 45°

Detail "A"

Detail "A"

1.30/1.50

1.75ma

x.

Land Pattern Recommendation

(Unit: mm)

6x-1.27

8x-1

.5

5

8x-0.60

5.4

0°/8°

(2) Package type: PDIP- 8L
