Diodes APX339 User Manual
Features, General description, Applications
APX393/APX339
LOW VOLTAGE RAIL-TO-RAIL INPUT DUAL/QUAD
COMPARATORS
APX393/APX339 Rev. 5
1 of 8
FEBRUARY2008
©
Diodes Incorporated
•
Guaranteed 2.7V and 5V performance
•
Industrial temperature range (-40°C to +85°C)
•
Low supply current: 60 µA per Channel
•
Input Common Mode Voltage (V-+0.2V to V+ -0.2V)
•
Low output saturation voltage @ 200 mV
•
Manufactured in standard CMOS process
•
MSOP-8L, SOP-8L, and TSSOP-14L available in
“Green” Molding Compound (No Br, Sb)
•
Lead-free Finish / RoHS Compliant (Note 3)
The APX393/339 are low voltage (2.5V to 5.5V) dual and quad
comparators. The APX393 is the dual version available in the
8-pin SOP and MSOP packages. The APX339 is the quad
version available in 14-pin TSSOP package. The APX393/339
are designed to efficiently minimize cost, space, and power
consumption for portable consumer products. They have open
drain output to connect to the logic supply through a pull-up
resistor and allow interfacing to a variety of logic families.
•
Mobile communications
•
Notebooks and PDA’s
•
Battery powered electronics
•
General purpose portable device
•
General purpose low voltage applications
APX 3XX XX G - 13
S : SOP-8L
Part Number
Package
39 : Quad (Note 2)
Packing
Green
G : Green
93 : Dual (Note 1)
M8 : MSOP-8L
TS : TSSOP-14L
13 : Tape & Reel
Device
Package
Code
Packaging
(Note 4)
13” Tape and Reel
Quantity
Part Number Suffix
APX393M8G-13 M8 MSOP-8L 2500/Tape
&
Reel
-13
APX393SG-13 S SOP-8L
2500/Tape
&
Reel
-13
APX339TSG-13 TS TSSOP-14L
2500/Tape
&
Reel
-13
Notes:
1. APX393 is only available for MSOP-8L and SOP-8L.
2. APX339 is only available for TSSOP-14L.
3. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at
4. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
Features
General Description
Applications
Ordering Information
