AH1801

MICROPOWER, ULTRA-SENSITIVE HALL EFFECT

SWITCH

AH1801 Rev. 7

2 of 10

FEBRUARY 2009

www.diodes.com

©

Diodes Incorporated

(1) SC59

(2) DFN2020-3

1. Vdd

GND 3.

2. Output

( Top View )

1. Vdd

3. Output

3. GND

( Top View )

(3) DFN2020-6

1. Vdd

2. NC 3. Output

4. NC

6. NC

5. GND

( Top View )

Notes: 3. NC is “No Connection”, which is recommended to be tied to ground.

Pin Name

P/I/O

Description

Vdd

P/I

Power Supply Input

GND

P/I Ground

Output O

Output

Pin

NC

No

Connected

Pin Assignment

Pin Descriptions
