Data Sheet

Two Phase Dual-coil High Voltage Smart Fan Motor Driver with FG/RD AH9281/82

Oct. 2011 Rev. 1. 4 BCD Semiconductor Manufacturing Limited

14

Mechanical Dimensions

TO-95 Unit: mm(inch)

1.295(0.051)

1.803(0.071)

0.610(0.024)

MIN

0.360(0.014)

0.510(0.020)

5.105(0.201)

5.359(0.211)

0.330(0.013)

0.432(0.017)

0.950(0.037)

REF

14.000(0.551)

16.000(0.630)

0.381(0.015)

0.581(0.023)

3.531(0.139)

3.785(0.149)

1.220(0.048)

1.620(0.064)

1.150(0.045)

1.350(0.053)

2.250(0.089)

2.450(0.096)

Package Sensor Location

(For Hall IC)
