Data Sheet

Two Phase Dual-coil High Voltage Smart Fan Motor Driver AH9280

Oct. 2011 Rev. 1. 2 BCD Semiconductor Manufacturing Limited

11

Mechanical Dimensions

TO-94 Unit: mm(inch)

Package Sensor Location

3.780(0.149)

4.080(0.161)

0.500(0.020)
0.700(0.028)

0.700(0.028)

0.900(0.035)

0.360(0.014)
0.510(0.020)

4.980(0.196)

5.280(0.208)

0.380(0.015)
0.550(0.022)

0.360(0.014)

0.500(0.020)

14.000(0.551)
15.300(0.602)

1.270(0.050) TYP

3.710(0.146)

3.910(0.154)

45

°

TYP

3.450(0.136)
3.750(0.148)

1.100(0.043)
1.400(0.055)

2.000(0.079)

2.300(0.091)

(For Hall IC)

1.520(0.060)
1.720(0.068)
