Data Sheet

TWO PHASE DUAL-COIL CMOS SMART FAN MOTOR DRIVER AH9279

Oct. 2011 Rev. 1. 3 BCD Semiconductor Manufacturing Limited

5

Electrical Characteristics

V

CC

=12V, T

A

=25°C, unless otherwise specified.

Parameter Symbol

Conditions

Min

Typ

Max

Unit

Supply Voltage

V

CC

Operating 3.5

16

V

Supply Current

I

CC

Average

3.5

5

mA

Output Current

I

OUT

500

mA

Output Leakage Current

I

LEAKAGE

V

OUT

=24V

0.1 10

µA

Saturation Voltage

V

SAT

I

OUT

=350mA

600

1000

mV

Output ON Time

t

ON

0.8

S

Output OFF Time

t

OFF

5

S

Output Zener Break-down
Voltage

V

Z

35 V

Thermal Resistance
(Junction to Case)

θ

JC

49

°C

/W


Magnetic Characteristics

V

CC

=12V, T

A

=25°C, unless otherwise specified.

Parameter Symbol

Min

Typ

Max

Unit

Operating Point

B

OP

25

50

Gauss

Releasing Point

B

RP

-50

-25

Gauss

Hysteresis B

HYS

50

Gauss
