AH293
LOW VOLTAGE HALL-EFFECT SMART FAN MOTOR
CONTROLLER
AH293
Document number: DS31048 Rev. 6 - 2
6 of 8
www.diodes.com
June 2010
© Diodes Incorporated
Ordering Information
AH 293 - Y G - 13
Packing Package Green
Y : SOT89-5L 13 : Tape & Reel G : Green (Note 5)
Device
Package
Code
Packaging
(Note 6, 7)
Bulk 13” Tape and Reel
Quantity
Part Number
Suffix
Quantity
Part Number
Suffix
AH293-YG-13 Y SOT89-5L NA NA 2500/Tape & Reel -13
Notes: 5. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at
http://www.diodes.com/products/lead_free.html.
6. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
http://www.diodes.com/datasheets/ap02001.pdf.
7. Reverse taping as shown on Diodes Inc. Surface Mount (SMD) Packaging document AP02007, which can be found on our website
http://www.diodes.com/datasheets/ap02007.pdf.
Marking Information
1 2 3
5 7 4
293 Y W X
(Top View)
Y : Year : 0~9
W : Week : A~Z : 1~26 week;
X : Internal code
a~z : 27~52 week;
z represents 52 and 53 week
A~Z : Green
SOT89-5L
