AH292
LOW VOLTAGE HALL-EFFECT SMART FAN MOTOR
CONTROLLER
AH292
Document number: DS31049 Rev. 7 - 2
2 of 8
June 2010
© Diodes Incorporated
Pin Descriptions
Pin Name
Description
FG
Frequency Generation
Vdd Input
Power
DO Output
Pin
DOB Output
Pin
GND Ground
Functional Block Diagram
Hall
Plate
Control Logic
Regulator
Lock detect,
shutdown and
automatic re-start
Vdd
GND
DOB
DO
Amp.
FG
