AH288
HIGH VOLTAGE HALL-EFFECT SMART FAN MOTOR
CONTROLLER
AH288 Rev. 12 2 of 9 APRIL 2010
DS31040 www.diodes.com © Diodes Incorporated
Ordering Information
AH288 - Y L - 13
Packing Package Lead Free
L : Lead Free (Note 1) Y : SOT89-5L 13 : Tape & Reel
G : Green
Device
Package
Code
Packaging
(Note 3)
13” Tape and Reel
Quantity Part Number Suffix
AH288-YL-13 Y SOT89-5L 2500/Tape & Reel -13
AH288-YG-13 Y SOT89-5L 2500/Tape & Reel -13
Notes: 1. AH288-YL-13 will be replaced by AH288-YG-13
2. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at
http://www.diodes.com/products/lead_free.html.
3. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
http://www.diodes.com/datasheets/ap02001.pdf.
4. Reverse taping as shown on Diodes Inc. Surface Mount (SMD) Packaging document AP02007, which can be found on our website
http://www.diodes.com/datasheets/ap02007.pdf.
1
2
3 7 4
5
DOB DO
GND
FG Vdd
SOT89-5L
288
( Top View )
Pin Name Pin No. Description
Vdd 1 Input power
GND 2 Ground
DO 3 Output pin
DOB 4 Output pin
FG 5 Frequency generation
Pin Assignments
Pin Descriptions
